FTTH Mini FC UPC Pigtailed 1X8 Fiber Optic Splitter Plc

FTTH Mini FC UPC Pigtailed 1X8 Fiber Optic Splitter Plc
FTTH Mini FC UPC Pigtailed 1X8 Fiber Optic Splitter Plc

Large Image :  FTTH Mini FC UPC Pigtailed 1X8 Fiber Optic Splitter Plc

Product Details:
Place of Origin: China
Brand Name: Geto Telecom
Certification: ISO 9001: 2015
Model Number: FOS1-2PFC1-2
Payment & Shipping Terms:
Minimum Order Quantity: 50
Price: $1.6-2.0
Packaging Details: Woven bag + Pallet/ Wooden box
Delivery Time: 10-15days
Payment Terms: L/C, T/T
Supply Ability: 1000000 Piece/Pieces per Month

FTTH Mini FC UPC Pigtailed 1X8 Fiber Optic Splitter Plc

Description
Product Name: PLC Splitter Cable: 0.9mm, 2.0mm, 3.0mm
Connector Type: FC/UPC Applications: FTTH FTTB FTTX PON CATV
Type: Single Mode Operating Temperature: -40~+75℃
Pigtail Length: 1m, 1.5m Or Customized Warranty Time:: 6 Months
Features:: Good Temperature Stability Test Wavelength: 1310nm
Working Wavelength: 1260nm~1650nm Service: OEM ODM
High Light:

1X8 Fiber Optic Splitter Plc

,

FTTH Fiber Optic Splitter

,

FTTH Fiber Splitter 1x8



Description
PLC splitter is based on plannar Lightwave circuit technology and precision aligning process, can divide a single/dual optical input(s) into multiple optical outputs uniformly and is denoted 1xN or 2xN. PLC splitter is applied in FTTX deployments, PON networks, CATV links and optical signal distribution currently.







Applications

FTTH,FTTB,FTTX Systems
LAN,WAN and Metro Networks
Analog/Digital Passive Optical Networks
CATV Networks
Test Equipment
Other applications in fiberoptic systems

Types 1x2 1x4 1x8 1x16 1x32
Test wavelength 1310nm
Working wavelength 1260nm~1650nm
Interface model FC/UPC
Insertion loss (dB) (P/S level) 3.8/4.0 7.1/7.3 10.2/10.5 13.5/13.7 16.5/16.9
Loss uniformity (dB) 0.4 0.6 0.8 1.2 1.5
Return loss (dB) (P/S level) 55/50 55/50 55/50 55/50 55/50
Polarization dependent loss (dB) 0.2 0.2 0.2 0.25 0.25
Directionality (dB) 55 55 55 55 55
Wavelength dependent loss (dB) 0.3 0.3 0.3 0.5 0.5
Temperature stability (dB) 0.4 0.4 0.4 0.5 0.5
Features Good temperature stability
Low insertion loss, high return loss
Good interchangeability, good repeatability



Features

Excellent Mechanical,Small Size
High Reliability
Low insertion Loss and low Polarization Dependent loss
High channel counts
Excellent Environmental Stability and Widely Used






Product show

Free Sample Pigtail Type FTTH FC UPC 1x2 PLC Fiber Optic Splitter

Application

Less Expensive Buyer 1 16 Pigtail Optical Fiber splitter Fiber Optic Splitter PLC Cassette Type Splitter Price









Our service



1, Product consulting service
2, Cost-saving advice
3, Fast response speed to needs
4, Professional and complete reference documents
5, Safe and cheap transportation solutions
6, 7*24 Hours After Sales Service
