Product Details:
|
| Product Name: | Optic Fiber Patch Cord | Connector Type: | SC UPC |
|---|---|---|---|
| Fiber Type: | Gigabit Single Mode | Resistance Strength: | 45kg |
| Material: | PVC LSZH Material | Jumper Mode: | ≥200N |
| Tensile Strength:: | Tensile Strength: | Cable Outer Diameter: | 3mm |
| Minimum Bending Radius:: | 3.8cm | Warranty Time:: | 6 Months |
| Use:: | Ftth Systems | Color:: | Agua |
| High Light: | 125um Optic Fiber Patch Cord,50um Optic Fiber Patch Cord,OM3 Multimode Patch Cord |
||
Support Ordering Parameters
1) Connector type: FC, SC, LC, ST
2) Ferrule End-face: PC, UPC, APC
3) Core Type: Single-mode (SM: 9/125um), Multimode (MM: 50/125um or 62.5/125um)
4) Cable Quantity: Simplex, Duplex
5) Cable Diameter: φ3.0mm,φ2.0mm, φ0.9mm
6) Cable Length: 3,5,10,15 meter or customized
7) Cable type: PVC, LSZH.Armored
8) patch cord/pigtailSupport Ordering Parameters:
Feature
1)Low Insertion loss
2)High return loss
3)Good Repeatability
4)Good Interchange
5)Excellent Environmental Adaptability
Application
1)Communication rooms
2)FTTH (Fiber to The Home)
3)LAN (Local Area Network)
4)FOS (fiber optic sensor)
5)Fiber Optic Communication System
6)Optical fiber connected and transmitted equipment
7)Defense combat readiness
Technical Parameters
power cable clamp
| Connetor Type | FC-FC FC-SC FC-LC FC-ST LC-LC LC-SC LC-ST SC-SC SC-LT ST-ST |
| Number of plugs | >1000 times |
| Tensile strength | ≥200N |
| Bending radius | >3.8cm |
| Light decay | <0.1dB |
| Repeatability | Less than 0.2dB |
| Exchangeability | Less than 0.1dB |
| Length | 3M or Customized |
| Wavelength | 1310nm or 1550nm |
|
Fiber
|
10G OM3 |
| 10G OM4 | |
| Connector | LC,FC,SC,ST |
| Insertion Loss | Less than 0.3dB |
|
Return Loss
|
UPC ≥ 50dB |
| SPC ≥ 55dB | |
| APC ≥ 60dB (typ.65dB) | |
| Cable |
Simplex, Duplex Φ3.0mm, Φ2.0mm, Φ0.9mm PVC or LSZH |
