Product Details:
|
| Product Name: | FTTH 2 Port ATB Access Terminal Box | Dimension: | 80*100 |
|---|---|---|---|
| Adapter: | SC&LC- DX | Color: | White |
| Material: | ABS | Service: | OEM ODM |
| Pigtail: | SC/LC | Warranty Time: | 12 Months |
| High Light: | ATB Fiber Optic Access Terminal Box,2 Core Fiber Optic Terminal Box,APC Duplex Fiber Optic Terminal Box |
||
Description
Fiber Optic Adapter Panel is a user terminal product that achieves fiber-to-desktop solutions with a reasonable design of internal space. For home or work area, complete dual-core fiber access and port output, can fully meet the requirements
of fiber bending radius, and protect the fiber out of the fiber core to provide safe protection. Appropriate radius of curvature, allowing a small amount of redundant fiber inventory, to achieve FTTD (fiber to desktop) system applications.
Specification
| Item | Value |
| Application | 3.0*2.0mm drop cable or indoor cable |
| Fiber diameter | 125um |
| Tight cladding diameter | 250um&900um |
| Mode of application | Single mode&duplex mode |
| Tensile strength | >50N |
| End-usd temperature | -40~85 degree Centi |
| Adaptor | SC&LC |
| Insertion loss | <0.2dB(1310nm&1550nm) |
| output | 2 |
| Size | 80*100*23mm |
